Main features:
Safety explosion-proof is suitable for occasions with electric hazards.
Equipped with a stepless speed changer, the speed can be adjusted manually. Reliable performance, stable flow, large torque, low noise, suitable for a variety of pump heads and hoses.
Can run continuously for a long time, simple maintenance
Large flow design is suitable for operation at 180-600rpm
Motor explosion-proof grade: ExdIIBT4.
▲When two pump heads are installed, after the outlets of the two channels are combined, the flow can be doubled, the pulse amplitude can be doubled, and the fluid delivery will be more stable.
Safety explosion-proof is suitable for occasions with electric hazards.
Equipped with a stepless speed changer, the speed can be adjusted manually. Reliable performance, stable flow, large torque, low noise, suitable for a variety of pump heads and hoses.
Can run continuously for a long time, simple maintenance
Large flow design is suitable for operation at 180-600rpm
Motor explosion-proof grade: ExdIIBT4.
▲When two pump heads are installed, after the outlets of the two channels are combined, the flow can be doubled, the pulse amplitude can be doubled, and the fluid delivery will be more stable.
| Speed range | 280-600rpm forward and reverse reversible | Flow range 19.6-12000 | mL/min |
| Applicable power supply | AC 380V | Speed regulation method | Manual stepless speed regulation |
| Working environment | Temperature 0-40℃, humidity <80% | Dimensions | 424 x 250 x 309（mm） |
| Drive weight | 30kg | Protection level | IP31 |
| Motor explosion-proof grade | ExdIIBT4 | Motor fan power supply | AC 380 |
| Drive | Applicable pump head | Applicable hose | Maximum reference flow range | Number of channels |
|
FB600S-02 |
YZ35 | 73#82# | 2800-12000 | 1 |
| KZ25 | 15#24#35#36# | 单通道843-6000 | 1 | |
| YZ1515 | 13# 14# 19# 16# 25# 17# 18# | 单通道19.6-2280 | N | |
| YZ2515 | 15# 24# | 单通道448-1600 | N |
