Small flow liquid filling peristaltic pump OEM05

Beautiful appearance, small size, convenient installation, simple and intuitive operation, suitable for OEM supporting use.

Flow range:Maximum flow: 2280ml/min

Maximum number of channels:1 channel

Introduction

Parameter

Guide

video

main feature

▲57 stepping motor drive, multiple units can be used in series, and the speed can be adjusted individually. .

▲Optional 0-5V, 0-10V, 4-20mA external control module, control start and stop, speed, direction controlled by a three-position switch

▲Beautiful appearance, small size, convenient installation, simple and intuitive operation, suitable for OEM supporting use.

range of rotation 1-300rpm, adjustable speed Speed resolution 1rpm
motor 57 stepper motor External speed control 0-5V, 0-10V, 4-20mA optional
Display function 3-digit LED digital tube displays the current speed Power consumption ≤45W
Applicable power supply   AC 220V Applicable power supply Ambient temperature 0~40℃, relative humidity <80%
Drive model Applicable pump head Applicable hose Maximum reference flow Number of channels
(ml/min)
OEM05 YZ1515 13#14#19#16#25#17#18# ≤2280 1
YZ2515 15#24# ≤1740 1
DG系列    Wall thickness≤1mm, inner diameter≤3.17mm ≤48 1

相关产品

*If you encounter any operation or quality problems of Qili constant flow pump, please contact us in time.

*Baoding Qili constant flow pump Co., Ltd. guarantees 7 * 24 hours online.

*Qili constant flow pump brand products have a one-year warranty and lifelong maintenance.

*The product picture, model, data, function, performance, motor model, specification and other parameters of this website are for reference only. Qili constant flow pump can improve the above content. For more information, please refer to the product manual. Unless otherwise specified, the data contained in this website are the internal test results of Qili constant flow pump.
